UVIC-5DT2 [5MP IP]

UVIC-5DT2 [5MP IP]

  • •    High quality imaging with 5MP resolution;
  • •    1/2.8″SONY Starvis Back-illuminated CMOS sensor;
  • •    Support H.264/H.264+/H.265/H.265+/JPEG/AVI Compression ;
  • •    minimum Illumination:Color: 0.008 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
  • •    Infrared Distance:25m;
  • •    Support Intrusion Detection,motion detection based on human detection;
  • •    Support DWDR: 50dB
  • •    Housing:Metal (Ring Plastic) , IP67
Category: Tag:

Description

mage Sensor 1/2.8″ SONY Starvis Back-illuminated CMOS sensor
Resolution 5MP
Effective Pixels 2616 (H)*1964 (V)
Compression H.264/H.264+/H.265/H.265+/JPEG/AVI
Audio Compression G711A/U
TV System PAL/NTSC
Electronic Shutter Time Auto: PAL 1/25-1/10000Sec; NTSC 1/30-1/10000Sec
Minimun Illumination Color: 0.008 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
S/N Ratio ≥52dB
Scanning System Progressive
Video Output Network
Reset Button Optional
Lens
Focus Length 3.6mm
Focus Control Fixed
Lens Type Fixed
Pixels 4MP
Night Vision
Infrared LED 42µ x 2PCS
Infrared Distance 25M
IR Status Auto Control
IR Power On Smart, Manual & Timed mode
Network
Ethernet RJ-45 (10/100Base-T)
Wireless N/A
Protocol TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,  RTCP ,PPPoE, NTP,  ,  SMTP, UDP
ONVIF Support ONVIF 19.12(Profile S/T/G)
P2P YES
POE Internal, Support IEEE 802.3af
Video Delay 0.3S (Within the Lan)
Main Stream 1 2592*1944@20fp
Main Stream 2 2560*1440@25fp
Main Stream 3 1920*1080@30fps
1280*720@30fps
Sub Stream 1 720*480@20fps
720*480@30fps
Sub Stream 2 352*288@25fps
352*288@30fps
Sub Stream 3 N/A
Tri Stream N/A
IE Brower IE8-11, Google Chrome, Firefox , Mac Safari
Smart Phone iPhone, Android
