UVIC-8WT21M-A [8MP IP]

UVIC-8WT21M-A [8MP IP]

  • •    High quality imaging with 8MP resolution;
  • •    2.7-13.5mm Motor Zoom;
  • •    1/2.7″SmartSens CMOS sensor;
  • •    Support H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG Compression ;
  • •    minimum Illumination:0.01Lux,Infrared Distance:25m;
  • •    Support HDR: 120dB
  • •    Housing: Metal, IP67
Category: Tag:

Description

Image Sensor 1/2.7″  SmartSens CMOS sensor
Resolution 8MP
Effective Pixels 3872(H)*2180(V)
Compression H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG
TV System PAL/NTSC
Electronic Shutter Time Auto: PAL 1/25-1/10000Sec; NTSC 1/30-1/10000Sec
Minimun Illumination 0.01Lux
S/N Ratio ≥52dB
Scanning System Progressive
Video Output Network
Reset Button Optional
Lens
Focus Length 2.7-13.5mm Motor Zoom
Focus Control Auto
Lens Type Auto
Pixels 8MP
Night Vision
Infrared LED 42µ x 2PCS
Infrared Distance 25M
IR Status Auto Control
IR Power On Manual & Timed mode
Network
Ethernet RJ-45 (10/100Base-T)
Wireless /
Protocol TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP,  RTCP ,PPPoE, NTP,  SMTP, UDP
ONVIF Support ONVIF 2.4(Profile S/T/G)
P2P YES, Support QR Code
POE Internal, Support IEEE 802.3af
